Switch rocker decorator single pole 15A 120/277VAC white

Manufacturer: Hubbell Wiring Devices | Catalog # RSD115W | Electrozad South Part # 134159
$5.56 /ea
pc
Log in or register to view your price, purchase history, and more!
2 available

For Delivery

Not in local stock *
Check another branch
Specification Sheet Product Catalog Page D BRAND LOGO IMAGE URL H TECHNICAL DRAWING URL P WARRANTY URL
Switch rocker decorator, single pole, color white.

Technical Information

Action
Positive Snap, Off
Actuator
Rocker
Applications
For Residential Wiring Devices
Contact Configuration
2 Position
Contact Rating
Per UL 20
Enclosure
None
Indicator
None
Material
Composite
Mounting Type
Flush, Screw
Number of Poles
1
Operating Cycles
30000
Operating Temperature
Max Continuous- 60 Degrees C, Minimum- -20 Without Impact
Size
Standard Sized
Standard
CSA,UL Standard 20
TC Connection
Push Wire and Terminal Screws
Temperature Rating
60 degrees C Maximum Continuous, -20 degrees C Minimum Continuous without Impact
Type
General Purpose, Standard, 2 Position
Wattage
4,155 Watt

Manufacturer Information

Brand
Hubbell Wiring Device Kellems
Sub Brand
AC Decorator Switches

General Product Info

12-Digit UPC
883778101137
Color
White
Environmental Conditions
Indoor Dry unless protected by additional means
GTIN
00883778101137
Product UPC
88377810113

Dimensions

Height
1.3 in
Length
4.200 in
Width
1.470 in

Certifications & Compliance

Country of Origin
China
Overview
  • Ultrasonically welded cover and base
  • Smooth, quiet rocker
  • Self-grounding feature is standard
