LEVITON T5825-W RECEPTACLE 20A 125V TR TAMPER RESISTANT TSLOT DECORA WHITE

Manufacturer: Leviton Manufacturing | Catalog # T5825-W | Electrozad South Part # 182124
$4.95 /ea
ea
Log in or register to view your price, purchase history, and more!
698 available

For Delivery

Not in local stock *
Check another branch
Specification Sheet MDM SAFETY DATA SHEET Installation / Instruction Manual MSDS | SDS Safety Sheet
Ultrasonically welded, 20A Tamper-Resistant, Decora duplex receptacle. Residential grade, NEMA 5-20R, side wired only, White.

Technical Information

Amperage
20 A
Applications
Commercial
Conductor Size
14 AWG
Connection Type
Quickwire Push-In and Side Wired
Grade
Commercial
Material
Thermoplastic
Mounting Type
Wallbox, Flush
NEMA
5-20R
Number of Phases
1
Number of Poles
2
Number of Wires
3
Size
4.2 H x 1.351 W x 1.184 D IN
Standard
CSA Certified (File 152105),NOM,UL (Listed)
TC Connection
Quickwire Push-In and Side Wired
Temperature Rating
-40 degrees C to 60 degrees C
Termination Type
Side Wire
Torque
14 lb-in
Type
Outlet, Tamper-Resistant
Voltage
125 V
Wire Size
14 AWG

Manufacturer Information

Brand
Leviton
Sub Brand
Decora®

General Product Info

12-Digit UPC
078477450352
Color
White
Environmental Conditions
UL 94 Requirements, V2 Rated Flammability
GTiN
00078477450352
Product Type
Decora
Product UPC
07847745035

Dimensions

Warranty Length
2 yr

Certifications & Compliance

Country of Origin
China
