PANDUIT BT1M-C BARBTY 4"L MINIATURE NYLON CABLE TIE TYRAP WHITE 100/PK

Manufacturer: Panduit | Catalog # BT1M-C | Electrozad South Part # 19156
$20.47 /c (100 ea)
ea
Order in multiples of 100 (pack qty)
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Product Brochure
Dome-Top® barb ty cable tie with miniature cross section for indoor use. Dome-top head features unique patented design with round, smooth edges. Stainless steel locking barb provides consistent performance, reliability and infinite adjustability through entire bundle range. High strength and low thread force, curved tip is easy to pick up from flat surfaces and allows faster initial threading to speed installation and UL Listed for use in plenum or air handling spaces per NEC.

Technical Information

Applications
General Use
Body Thickness
0.036 in
Body Width
0.095 in
Bundle Diameter
23 mm
Material
Nylon 6.6/Polyamide
Max Operating Temperature
185 degrees F
Minimum Operating Temperature
-60 degrees C
Standard
CSA,E2186,UL
Tensile Strength
80 N
Type
Miniature, Barb, Internal Toothing, Plenum, Locking

Packaging

Package Qty
100
Standard Packaging Qty
100/Pack

Manufacturer Information

Brand
Panduit
Sub Brand
Dome-Top

General Product Info

12-Digit UPC
074983413027
Color
Natural
Environment
Indoor
GTIN
00074983413027
Product UPC
07498341302

Dimensions

Length
4 in
Overall Length
4 in
Thickness
0.9 mm
Width
2.4 mm

Certifications & Compliance

Country of Origin
Costa Rica
