HUB RCD101W SWITCH 2 SINGLE POLE SELF GROUNDING SIDE WIRE 15A TERMINATION 120-277VAC HOME SELECT DECORA

Manufacturer: Hubbell Wiring Devices | Catalog # RCD101W | Electrozad South Part # 199817
$27.44 /ea
pc
Log in or register to view your price, purchase history, and more!
1 available

For Delivery

Not in local stock *
Check another branch
Specification Sheet Product Catalog Page Installation / Instruction Manual
tradeSELECT® Combination quiet rocker switch/device. 1-pole and 15 A at 120 to 277 VAC switch. Side-wire. Low profile. Self-grounding feature is standard. -20 to 60..C operating temperature.

Technical Information

Action
Snap Switch
Actuator
Rocker
Amperage
15 A
Applications
Residential
Contact Configuration
Two Position
Contact Rating
15A
Current
15 A
Mounting Type
Flush, Screw
Number of Poles
2
Operating Cycles
30k
Operating Temperature
Max Continuous- 60 Degrees C, Minimum- -20 Without Impact
Size
Standard Sized Product
Standard
CSA,E3896,UL
TC Connection
Terminal Screws
Temperature Rating
60 degrees C Maximum Continuous, -20 degrees C Minimum Continuous without Impact
Type
2) Switches
Voltage
120/277 V
Wattage
4155 W

Manufacturer Information

Brand
Hubbell
Sub Brand
Trade-Select™

General Product Info

12-Digit UPC
883778110214
Color
White
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Finish
Matte
GTIN
00883778110214
Product UPC
88377811021

Dimensions

Height
1.2 in
Length
4.500 in
Width
1.550 in

Certifications & Compliance

Country of Origin
China
