PANDUIT PLT3S-M30 PAN-TY CABLE TIE 11.5"L STD HEAT STAB BLACK

Manufacturer: Panduit | Catalog # PLT3S-M30 | Electrozad South Part # 202775
$462.83 /m (1000 ea)
ea
Order in multiples of 1000 (pack qty)
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet
Pan-Ty® Cable tie. Standard cross section. Heat stabilized nylon 6.6. One-piece construction for consistent performance and reliability. Lowest threading force of any one-piece cable tie in the industry. Curved tip is easy to pick up from flat surfaces and allows faster initial threading to speed installation. For high temperature applications up to 115..C indoor use.

Technical Information

Applications
For Indoor use
Body Thickness
0.052 in
Body Width
0.19 in
Bundle Diameter
76 mm
Material
Heat Stabilized Nylon 6/6
Max Operating Temperature
115 degrees C
Minimum Operating Temperature
-60 degrees C
Standard
CSA,E2186,UL
Temperature Rating
-60 to 115 degrees C
Tensile Strength
222 N
Type
Standard, Locking

Packaging

Package Qty
1000
Standard Packaging Qty
1000/Pack

Manufacturer Information

Brand
Panduit
Sub Brand
Pan-Ty

General Product Info

12-Digit UPC
074983564828
Color
Black
Environment
Indoor
GTIN
00074983564828
Product UPC
07498356482

Dimensions

Length
292 mm
Overall Length
292 mm
Thickness
1.3 mm
Width
4.8 mm

Certifications & Compliance

Country of Origin
CR,MY
