Connector 3P4W 600V 60A 3 phase IP67 black

Manufacturer: Hubbell Wiring Devices | Catalog # HBL2320SW | Electrozad South Part # 214843
$178.19 /ea
pc
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Brochure Product Catalog Page Installation / Instruction Manual D BRAND LOGO IMAGE URL H TECHNICAL DRAWING URL I INSTALL ASSEMBLY INSTRUCTIONS URL P WARRANTY URL
Watertight IEC pin and sleeve connector with 3 pole, 4 wire, 3 Phase 600V.

Technical Information

Amperage
20 A
Applications
Heavy Duty Industrial Shrouded Watertight
Conductor Size
14-8 AWG
Current
20 A
Dielectric Strength
Withstands 2,000V minimum
Grade
Industrial
Horsepower
2 hp
Material
Thermoplastic
Mounting Type
Screw, Surface
NEMA
L6-20R
Number of Phases
1
Number of Poles
2
Number of Wires
3-Wire Grounding
Operating Temperature
-40 degrees C
Size
Standard
Standard
4X,CSA,Type 12,Type 4,UL
TC Connection
Screw Terminal
Type
Heavy Duty, Shrouded
Voltage
250 V
Wattage
5000 W
Wire Count
3
Wire Size
16-8 AWG

Manufacturer Information

Brand
Hubbell Wiring Device Kellems
Sub Brand
Twist-Lock®

General Product Info

12-Digit UPC
783585231082
Color
Gray and White
Environmental Conditions
Watertight
GTIN
00783585231082
Product UPC
78358523108
Weight
0.55 lb

Dimensions

Height
2.69 in
Length
3.75 in
Width
3.300 in

Certifications & Compliance

Country of Origin
USA
Overview
  • Alignment arrows with lock and unlock symbols provide a visual indication that devices are properly connected
  • UL type 4X environmental seal while in use and when closed
  • High impact, thermoplastic housing for heavy-duty industrial environments
  • Catalog number and color coded voltage rating are visible even when in use
