Pan-Term® DV10-250-D Disconnect, Yellow, Vinyl, 10-12 AWG, 0.25" Tab, PK500

Manufacturer: Panduit | Catalog # DV10-250-D | Electrozad South Part # 21549
$588.22 /m (1000 ea)
ea
Log in or register to view your price, purchase history, and more!
150 available

For Delivery

Not in local stock *
Check another branch
Specification Sheet D BRAND LOGO IMAGE URL H TECHNICAL DRAWING URL
The vibration resistant female disconnect is made of brass and is tin-plated. It is barrel insulated in yellow vinyl housing. It has a tab size of 0.250 x 0.032" (6.3 x 0.8 mm) and supports a wire range of 12-10 AWG (4.0-6.0 mm..). It is 1.03" (26.2 mm) long and 0.3" (7.6 mm) wide. The disconnect has a funnel entry barrel configuration and a sleaved barrel. It comes in boxes of 500.

Technical Information

Barrel Type
Sleeved Barrel
Color Coding
Yellow
Material
Brass
Max Operating Temperature
150 degrees C
TC Connection
Funnel Entry
Temperature Rating
221 F
Type
Disconnect
Wire Size
#10 AWG

Packaging

Package Qty
500

Manufacturer Information

Brand
Panduit
Sub Brand
Pan-Term®

General Product Info

12-Digit UPC
074983821051
Color
Yellow
Finish
Tinned
GTIN
00074983821051
Product UPC
07498382105
UNSPSC
39121409

Dimensions

Height
0.13 in
Overall Length
1.03 in
Width
0.3 in

Certifications & Compliance

BAA | Buy American Compliant
Y
Country of Origin
Mexico
