PANDUIT OCF3IW-E LD3 LOW VOLTAGE OUTSIDE CORNER FITTING

Manufacturer: Panduit | Catalog # OCF3IW-E | Electrozad South Part # 235743
$2.19 /ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Installation / Instruction Manual
The outside corner fitting is a Surface Raceway fitting designed to transition your raceway around an outside corner while maintaining a 1 inch bend radius. It is designed to be used with the LD3 raceway and features a snap-on installation. It meets TIA/EIA, used in applications up to 50 V, and is Off White.

Technical Information

Applications
For Routing of Power or Low Voltage Data and Fiber Optic Cabling Along Perimeter Walls
Cover Type
Outside Corner
Material
Copper,PVC
Mounting Type
Snap-On
Type
Round, Fully Adjustable

Packaging

Package Qty
20

Manufacturer Information

Brand
Panduit
Sub Brand
Pan-Way

General Product Info

12-Digit UPC
074983262618
Color
Off-White
GTIN
00074983262618
Product UPC
07498326261

Dimensions

Height
0.44 in
Length
1.05 in
Overall Length
1.05 in
Width
26.7 mm

Certifications & Compliance

Country of Origin
Costa Rica
