DP6 ™ PLUS UTP Patch panel with 24 RJ45, 8-position, 8-wire ports. Each port is 100% tested to ensure NEXT and RL performance and is individually serialized to support traceability. Utilize 110 punch down termination on back panel and includes retention cap for each port. Each port contains a universal label that is colour-coded for T568A and T568B wiring schemes. Angled versions allow for higher density applications by easily routing the patch cords to each side of the panel eliminating the need for horizontal cable management. Terminate 4-pair, 22 to 26 AWG, 100 Ohm, solid or stranded twisted pair cable.
