Cat 6 24 AWG UTP Copper Patch Cord, 5 ft, Blue

Manufacturer: Panduit | Catalog # UTPSP5BUY | Electrozad South Part # 258849
$23.37 /ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Brochure D BRAND LOGO IMAGE URL H TECHNICAL DRAWING URL P WARRANTY URL
The TX6™ PLUS Cat 6 UTP Patch Cord is a 5-Foot, Blue cord constructed of 24 AWG, unshielded, twisted pair, stranded, CM cable with high-performance modular plugs. Its tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. The slender strain relief boot provides easy access in high-density applications. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.

Technical Information

Applications
Ethernet 10BASE-T, 100BASE-T (Fast Ethernet), 1000BASE-T, 10GBASE-T, 155 Mb/s ATM, 622 Mb/s ATM, 1.2 Gb/s ATM, Token Ring 4/16, Digital Video and Broadband/Baseband Analog Video and VoIP
Boot Color
Clear
Cable Type
24 AWG U/UTP
Conductor Material
Copper
Conductor Size
24 AWG
Conductor Type
Stranded
Connector Type
Modular Plug
Material
Copper
Max Operating Temperature
140 degrees F
Minimum Operating Temperature
-10 degrees C
Performance Level
Category 6
Plug Type
Modular Plug
Temperature Rating
140 degrees F
Type
Category 6
Wire Size
24

Packaging

Package Qty
1

Manufacturer Information

Brand
Panduit
Sub Brand
PanNet

General Product Info

12-Digit UPC
074983170937
Color
Blue
GTIN
00074983170937
Jacket Material
PVC
Product UPC
07498317093

Dimensions

Cable Length
5 ft
Length
5.00
Outer Diameter
0.23 in
Outside Diameter
5.8 mm
Overall Length
5 ft

Certifications & Compliance

BAA | Buy American Compliant
Y
Country of Origin
CN,CR,MX,RO,US
