LIMITRON TIME DELAY FUSE

Manufacturer: Bussman Cooper Fuses | Catalog # KLU-650 | Electrozad South Part # 266325
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 5 to 7 days
Specification Sheet Product Brochure
Eaton Bussmann Series Class L fuse, KLU, fast-acting, current limiting fuse, 650 A, bladable fuse, interrupting rating of 200 kA, 600 Vac

Technical Information

Amperage
650 A
Applications
Large Distribution Switchboards, Large Machinery Disconnects, Power Panelboards
Connection Type
Blade
End Type
Blade,Bolted
Interrupt Rating
200 kA
Mounting Type
Bolt-On
Response Time
5 S At 500%
Size
2.50 In Diameter X 8.63 In Length
TC Connection
Bolted Blade End X Bolted Blade End
Type
Current Limiting,Time Delay
Voltage
600 V

Manufacturer Information

Brand
Bussmann
Sub Brand
Limitron

General Product Info

12-Digit UPC
051712135030
Class
Class L
GTIN
00051712135030
Product UPC
51712135030
Weight
3.75 lb

Dimensions

Diameter
2.5 in
Height
2.5 in
Length
8.63 in
