Wall Switch Sensor, White

Manufacturer: Sensor Switch Inc | Catalog # WSX WH | Electrozad South Part # 268194
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 5 to 7 days
Specification Sheet Product Brochure Installation / Instruction Manual I INSTALL ASSEMBLY INSTRUCTIONS URL L WIRING DIAGRAM URL
Sensor Switch WSX Series. Digital Push-button programmable without removing cover plate - adjustable time delays & operating modes.

Technical Information

Applications
For Commercial and Residential Lighting Control Applications, Private Offices, Private Rest Rooms, Closets, Copy Rooms, or Any other Small Enclosed Space
Dimmable?
Yes
Lamp Life
87,600 hr
Lens Material
Plastic
Material
Plastic
Mounting Type
1-Gang Switch Box, Wall
Power Source
Hardwired
Sensing Range
180 degrees
Sensor Type
Passive Infrared
Temperature Rating
0 - 60 degrees C
Type
Single Relay, Auto On (Default)

Manufacturer Information

Brand
Lithonia Lighting

General Product Info

12-Digit UPC
753573767527
Color
White
Environment
Indoor
Environmental Conditions
Indoor
Finish
Gloss
GTIN
00753573767527
Product UPC
75357376752
Shape
Rectangular
Used With
LEDs, Electronic and Magnetic Ballasts, CFLs, and Incandescents
Weight
0.32 lb

Dimensions

Height
2.74 in
Length
1.63 in
Warranty Length
5 yr
Width
1.680 in

Certifications & Compliance

Country of Origin
Mexico,Mexico
Overview
  • WARRANTY: 5-Year Limited Warranty
  • WIRING: Line power and load wires are interchangeable, making it impossible to wire backwards
  • CONNECTIONS: Device accommodates powering over ground or neutral connection
  • GROUNDING: Self-grounding mounting strap
  • WIRING: Easy to install while helping to aid in energy code compliance, the WSX has a patented wiring method that enables them to function with or without a neutral connection
  • MOTION DETECTION: Small motion detection up to 20 feet (6.10 m)
  • COMPATIBILITY: Compatible with LEDs, electronic and magnetic ballasts, CFLs, and incandescents
  • CONSTRUCTION: Vandal resistant lens
  • DIMENSIONS: 2.74 in. H x 1.68 in. W x 1.63 in. D (70mm x 43mm x 41mm) - does not include ground strap
  • RATINGS: Energy Management Equipment, UL916 (E167435); RoHS compliant
