PANDUIT AST20-5-C100 TYRAP 8.4"L 214MM TIE ARIAL SUPPORT WEATH

Manufacturer: Panduit | Catalog # AST20-5-C100 | Electrozad South Part # 269551
$1,775.19 /m (1000 ea)
ea
Order in multiples of 100 (pack qty)
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Installation / Instruction Manual
Panduit AST25-5-C100 Aerial Support Ties with integral 1/2... (12.7mm) spacer for support strands are designed to keep equipment and cable clear of pole hardware. These ties and spacers together reduce inventory costs and allows for faster installation. They are releasable and re-usable, and do not require install tools. Supports bundles up to 2.5... (63.5mm) in diameter and is for use in outdoor environments. Made of weather-resistant polypropylene, is black in color and comes in packages of 100.

Technical Information

Applications
General
Bundle Diameter
2.00 IN
Material
Weather Resistant Polypropylene
Max Operating Temperature
115 degrees C
Minimum Operating Temperature
-60 degrees C
Mounting Type
Aerial Support
Tensile Strength
334 lb
Type
Aerial Support Tie

Packaging

Package Qty
100

Manufacturer Information

Brand
Panduit

General Product Info

12-Digit UPC
074983601042
Color
Black
Environment
Indoor,Outdoor
GTIN
00074983601042
Product UPC
07498360104

Dimensions

Length
8.40 IN
Overall Length
8.4 in
Width
1.16 in

Certifications & Compliance

Country of Origin
USA
