LUTRON MS-OPS5M-WH SENSOR MAESTRO PIR OCC 5A WHITE

Manufacturer: Lutron Dimmers | Catalog # MS-OPS5M-WH | Electrozad South Part # 277827
$39.63 /ea
pc
Log in or register to view your price, purchase history, and more!
10 available

For Delivery

Not in local stock *
Check another branch
Specification Sheet Product Catalog Page Installation / Instruction Manual
MAESTRO® Occupancy sensing switch combines a MAESTRO® switch with a passive infrared occupancy or vacancy sensor. Single-pole/3-way/multi-location. Occupancy version can be set to Auto-ON/auto-OFF or manual-ON/auto-OFF. Adjustable timeout (1, 5, 15 or 30 minutes) and high/low sensitivity adjustment. Crush/tamper resistant lens. Smart ambient light detection. Adaptive switching algorithm for extended relay life. XCT™ technology for fine motion detection.

Technical Information

Amperage
5 A
Applications
For Lighting Control
Body Material
Plastic
Enclosure
Plastic
Enclosure Material
Plastic
Material
Plastic
Mounting Type
Wall, Flush
Number of Poles
1
Operating Temperature
0 - 40 degrees C
Power Supply
120 V
Response Time
1, 5, 15, 30 min
Sensing Range
900 ft2 (82 m2) major motion coverage/400 ft2 (36 m2) minor motion coverage
Sensor Type
Passive Infrared
Standard
CUL,NOM,UL
Temperature Rating
0 degrees C to 40 degrees C
Type
3-Way/Single Pole, Multi-Location, Indoor
Voltage
120-277 V

Manufacturer Information

Brand
Lutron
Sub Brand
Maestro

General Product Info

12-Digit UPC
027557983570
Color
White/Gloss
Environmental Conditions
0 To 90% Humidity,Indoor Use Only,Non-condensing
Finish
Gloss
GTIN
00027557983570
Product UPC
02755798357

Certifications & Compliance

Country of Origin
China
