SIED HFC365NRA DISCONNECT CSA 400A 3P 4W 600V FUSED HD TY 3R SAFETY SWITCH

Manufacturer: Siemens Distribution | Catalog # HFC365NRA | Electrozad South Part # 280961
$2,831.71 /ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Catalog Page
Safety switch are heavy duty models intented for use in industrial rugged area where reliable service and maintenance free are required with fault current higher than 10 KA. Available in versions 2 poles 2 fuses solid neutral 240vac, 3 poles 3 fuses 240&600vac and 3 poles no fuses 600vac. Enclosures come in type 1 indoor use, type 12 industrial use, type 4X stainless steel corrosive area available with or without outlet receptacle. Available with window door to view fuses and contacts.

Technical Information

Action
Single throw
Actuator
SINGLETHROW
Applications
For Electrical Distribution
Connection Type
Screw
Enclosure
NEMA3R
Load Rating
4 W
Material
Steel
Number of Poles
3
Number of Wires
4
Operating Cycles
6000
Operating Temperature
-29 degrees C
TC Connection
MECHANICALLUGS
Temperature Rating
-20 to 120 degrees F Ambient
Type
Heavy Duty, Fused, Single Throw

Manufacturer Information

Brand
Siemens
Sub Brand
Safety Switches

General Product Info

12-Digit UPC
887621872878
GTIN
00887621872878
Housing Material
Steel
Product UPC
88762187287
