LEVITON 5362-SBU RECEPTACLE 20A 125V DUPLEX SELF GROUNDING BLUE

Manufacturer: Leviton Manufacturing | Catalog # 5362-SBU | Electrozad South Part # 282139

*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Duplex receptacle, NEMA 5-20R. 2-pole, 3-wire. Industrial series extra heavy duty specification grade. Straight blade. Self grounding. Contractor pack. Back and side 8-hole feed through wired. Steel strap. Leviton line of extra heavy duty industrial grade receptacles are designed and manufactured to withstand the harsh conditions typically associated with industrial environments. Available in a wide variety of configurations, including isolated ground, tamper resistant, hospital grade, etc. These industrial grade devices are the electrical contractor choice for use in factories, schools, hospitals and commercial office buildings.

Technical Information

Amperage
20 A
Applications
Commercial
Body Material
Thermoplastic Nylon
Conductor Size
14 - 10 AWG
Connection Type
Back and Side Wired
Device Type
Duplex Receptacle Outlet
Dielectric
2000 V
Dielectric Strength
2000 V
Enclosure
WD-6
Face Material
Nylon
Flamability Class
Rated V-2 Per UL 94
Grade
Commercial
Grounding
Self-Grounding
Horsepower
1 hp
Material
Thermoplastic
Mounting Type
Wall Box
NEMA
5-20R
Number of Phases
1
Number of Poles
2
Number of Wires
3
Operating Temperature
-40 degrees C
Size
46 H x 1.33 W x 19 D IN
Standard
ANSI C-73
TC Connection
Back & Side Wired
Temperature Rating
-40 degrees C to 60 degrees C
Temperature Rise
200 %
Termination Type
Back Wire,Side Wire
Torque
14 lb-in
Type
Heavy Duty, Narrow Body
Voltage
125 V
Wire Count
3
Wire Size
14 - 10 AWG

Manufacturer Information

Brand
Leviton
Sub Brand
Industrial Receptacles

General Product Info

12-Digit UPC
078477146941
Color
Blue
Environmental Conditions
Flammability (Rated V-2 Per UL94)
GTiN
00078477146941
Product UPC
07847714694

Dimensions

Warranty Length
10 yr

Certifications & Compliance

Country of Origin
Mexico
