Product image for Switches and Lighting Controls,Extra Heavy Duty Industrial Grade, Locking Toggle Switches, General Purpose AC, Three Way, 15A 120/277V AC, Back and Side Wired, White Key Guide
Image thumbnail 0
Image thumbnail 1
Email

Switches and Lighting Controls,Extra Heavy Duty Industrial Grade, Locking Toggle Switches, General Purpose AC, Three Way, 15A 120/277V AC, Back and Side Wired, White Key Guide

Manufacturer: Hubbell Wiring Devices | Catalog # HBL1203LW | Electrozad South Part # 317501
*Call For Price*
Log in or register to view your price, purchase history, and more!
1 available

For Delivery

Not in local stock *
Check another branch
Specification Sheet Product Catalog Page Installation / Instruction Manual D BRAND LOGO IMAGE URL H TECHNICAL DRAWING URL I INSTALL ASSEMBLY INSTRUCTIONS URL P WARRANTY URL
Switches and Lighting Controls,Extra Heavy Duty Industrial Grade, Locking Toggle Switches, General Purpose AC, Three Way, 15A 120/277V AC, Back and Side Wired, White Key Guide

Technical Information

Action
SPDT
Actuator
Double Ended Key
Amperage
15 A
Applications
Back and Side Wired
Base Material
Thermoset
Contact Configuration
2-Position
Contact Material
Silver Alloy
Contact Rating
Full Rated
Current
15 A
Enclosure
None
Flamability Class
UL 94V-2
Grade
Industrial
Indicator
Dot Indicates On
Lock Type
Non-Cylindrical
Material
Thermoset,Thermoset
Max Current
15 A
Max Voltage
277 V
Number of Poles
1
Operating Temperature
-40 degrees C
Screw Material
Brass
Size
4.06 in x 1.31 in x 1.13 in
Style
Three Way
TC Connection
Terminal Screws
Temperature Rating
Max Continuous- 75 Degrees C, Minimum- -40 Without Impact
Toggle Material
Metallic
Type
General Purpose, Standard, 3-Way, 2-Position
Voltage
120-277 V
Wattage
4,155 Watt
Wire Size
14-10 AWG

Manufacturer Information

Brand
Hubbell Wiring Device Kellems
Sub Brand
AC Toggle Switches

General Product Info

12-Digit UPC
783585188522
Color
White
GTIN
00783585188522
Product Series
Extra Heavy Duty
Product UPC
78358518852

Dimensions

Height
1.13 in
Length
4.06 in
Width
1.31 in

Certifications & Compliance

Country of Origin
China
Overview
  • Strip gauge for accurate wiring
  • Large brass binding head screws with deep slots
  • Lock circuits On or Off
