Pan-Lug™ LCCF3/0-12-X Compression Connectors - Lugs | Electrozad South
Product image for Pan-Lug™ LCCF3/0-12-X Compression Connectors - Lugs
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Image thumbnail 3
Email

Pan-Lug™ LCCF3/0-12-X Compression Connectors - Lugs

Manufacturer: Panduit | Catalog # LCCF3/0-12-X | Electrozad South Part # 317796
$3,318.37 /c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Installation / Instruction Manual D BRAND LOGO IMAGE URL H TECHNICAL DRAWING URL I INSTALL ASSEMBLY INSTRUCTIONS URL
Two-hole, long flared barrel, 3/0 AWG wire, 1/2 stud hole, 1 3/4 hole spacing, NEMA hole sizes and spacing.

Technical Information

Angle
Straight
Barrel Length
1.56 in
Barrel Type
Long
Color Coding
Purple
Material
Copper
Number of Holes
2
Size
3/0 AWG Class K and M and DLO
Stud Size
0.5 in
Tongue Thickness
0.14 in
Tongue Type
Standard
Tongue Width
1.06 in
Type
Compression Connectors - Lugs

Packaging

Package Qty
10

Manufacturer Information

Brand
Panduit
Sub Brand
Pan-Lug™

General Product Info

12-Digit UPC
074983753154
Color
White
GTIN
00074983753154
Product UPC
07498375315
UNSPSC
39121405

Dimensions

Overall Length
5.13 in

Certifications & Compliance

BAA | Buy American Compliant
Y
Country of Origin
Mexico
