Sensor switch single pole 120V 2A black

Manufacturer: Lutron Dimmers | Catalog # MS-OPS2-BL | Electrozad South Part # 319873
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 5 to 7 days
Specification Sheet Product Catalog Page Installation / Instruction Manual D BRAND LOGO IMAGE URL H TECHNICAL DRAWING URL I INSTALL ASSEMBLY INSTRUCTIONS URL P WARRANTY URL
Single-circuit PIR occupancy/vacancy sensor switch. All models feature Lutron exclusive XCT technology. Adjustable timeout - 1, 5, 15, or 30 minutes. Occupancy/vacancy version can be easily programmed to work as vacancy (manual-on) sensor. High-low sensitivity adjustment. 2 A rated for: incandescent/halogen, magnetic low-voltage, electronic low-voltage, fluorescents, CFLs, and LEDs.

Technical Information

Amperage
2 A
Applications
For Lighting Control
Body Material
Plastic
Enclosure
Plastic
Enclosure Material
Plastic
Material
Plastic
Mounting Type
Wallbox
Number of Poles
1
Operating Temperature
32 To 104 degrees F
Power Supply
120 V
Sensing Range
900 ft2 (82 m2) major motion coverage/400 ft2 (36 m2) minor motion coverage
Sensor Type
Passive Infrared
Standard
CUL,NOM,UL
Temperature Rating
0 - 40 degrees C Operating
Type
Occupancy Sensor Switch,Single-pole
Voltage
120 V

Manufacturer Information

Brand
Lutron
Sub Brand
Maestro

General Product Info

12-Digit UPC
027557982597
Color
Black
Environmental Conditions
0 To 90% Humidity,Indoor Use Only,Non-condensing
Finish
Gloss
GTIN
00027557982597
Product UPC
02755798259

Certifications & Compliance

Country of Origin
China
Overview
  • Complies with Title 20/24 Section 110.9 for automatic shutoff
  • Features passive infrared (PIR) motion detection with exclusive Lutron XCT Technology for fine motion detection, which is 2-3x better at picking up motion than other manufacturers
  • Smart Ambient Light Detection (ALD) can be programmed so lights stay off if enough natural light is present in the room
  • Single Pole only
  • Includes (1) Lutron Maestro 2A Motion Sensor Switch; Gloss Finish
  • Rated to work with up to 2A lighting; 120V
  • 180-degree sensor field of view (900 sq ft major motion & 400 sq ft minor motion coverage); Tamper-resistant lens
  • Easy button programming to customize timeout, sensor mode, or sensitivity
  • Available in 10+ colors; Pairs perfectly with Lutron Claro wall plates for consistent color matching (wall plates are sold separately)
  • Wire-Lead installation; Ground or Neutral Required
