LED - Static, High Bay

Manufacturer: Lithonia Lighting | Catalog # JEBL 30L 40K 80CRI WH | Electrozad South Part # 321616
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 5 to 7 days
Specification Sheet Product Brochure Installation / Instruction Manual I INSTALL ASSEMBLY INSTRUCTIONS URL
LED Economical Round Bay Light, 30,000 nominal lumens, 4000K, 80 color rendering index, White finish

Technical Information

Applications
Manufacturing,Warehouses
Average Rated Life
54,000 hr
Color Rendering Index
80 CRI
Color Temperature
4000 K
Dimmable?
Yes
Enclosure Type
IP65
Fixture Wattage
218 W
Lamp Type
LED
Lens Color
White
Lens Material
Tempered Glass
Lens Type
Clear Tempered Glass
Lumens
31423 lm
Material
Aluminum
Mounting Type
Pendant, Suspended
Power Source
Hardwired
Reflector Finish
Clear Polycarbonate or Diffuse Aluminum
Style
Traditional
Temperature Rating
-40 to 131 degrees F
Type
Round, General Distribution
Voltage
120 V
Wattage
220.000 W

Manufacturer Information

Brand
Lithonia Lighting
Sub Brand
Contractor Select

General Product Info

12-Digit UPC
191848153925
Color
White
Construction
New Construction,Remodel
Environment
Indoor
Environmental Conditions
Indoor
Finish
Gloss
Fixture Type
High Bay
GTIN
00191848153925
Housing Finish
White/Gloss
Housing Material
Die Cast Aluminum
Product UPC
91848153925
Shape
Round
Weight
12.3 lb

Dimensions

Height
5-3/16 in
Length
15.75 in
Width
15-3/4 in

Certifications & Compliance

Country of Origin
Vietnam,Vietnam
Overview
  • WARRANTY: 5-year limited warranty
  • VOLTAGE: Input voltage is MVOLT (120-277V) and HVOLT (347-480V)
  • INSTALLATION: Install 1/4 in. NPT eye bolt with 1/2 in. thick loop and 6 ft. cord with dimming lead provided for easy installation and optional surface mount brackets
  • DIMMING: 0-10V dimming standard for a dimming range of 100 to 10 percent
  • TECHNOLOGY: JEBL features a white die-cast aluminum housing along with a removable die-cast aluminum driver housing. Powder coat corrosion resistant finish provides 500 hours salt fog rating.
  • ENERGY SAVINGS: Easily replace 4-lamp T5HO, 6-lamp T8 with LEDs that save energy and reduce total cost of ownership
  • HOURS OF LIFE: L90 > 54,000 hours
  • BATTERY: Field-installable LED emergency driver sold separately
  • DIMENSIONS: diameter 13 in. x depth 5 in.
  • RATINGS: CSA listed to US and Canadian Safety Standards; Wet location listed
