KC26

Manufacturer: Burndy | Catalog # KC26 | Electrozad South Part # 32977
$54.44 /ea
pc
Log in or register to view your price, purchase history, and more!
28 available

For Delivery

Not in local stock *
Check another branch
Specification Sheet Product Brochure D BRAND LOGO IMAGE URL H TECHNICAL DRAWING URL
Mechanical Grounding Connector, Cable to Flat, 2-2/0 AWG (Str) / 2-3/0 AWG (Sol), 1/2" Stud; cross base flat: .88"

Technical Information

Applications
For Used to Ground One or Two Copper Cables to Steel Structures, Fence Posts, Transformers, Tap One or Two Cables from Bus Bar and Direct Burial
Body Width
0.88 in
Conductor Size
2-3/0 AWG Solid, 2-2/0 AWG Stranded
Conductor Type
Commercial Stranded Copper, Commercial Solid Copper (Run)
Direct Burial?
Yes
Material
Bronze
Mounting Type
1/2-13
Plated?
No
Plating Type
Unplated
Type
Mechanical

Manufacturer Information

Brand
Burndy
Sub Brand
Servit Post™

General Product Info

12-Digit UPC
781810255957
GTIN
00781810255957
Product UPC
78181025595

Dimensions

Diameter
3/4 in
Height
1-3/8 in
Length
2.12 in
Overall Length
2.12 in
Width
1.04 in

Certifications & Compliance

Country of Origin
USA
CSA
No
