COMPACT PRO HIGH BAY, LED, 15,000LM, 120

Manufacturer: Lithonia Lighting | Catalog # CPHB 15LM MVOLT 40K | Electrozad South Part # 366739
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 5 to 7 days
Specification Sheet Product Brochure Installation / Instruction Manual I INSTALL ASSEMBLY INSTRUCTIONS URL

Technical Information

Applications
For Retrofit, Warehouses
Average Rated Life
100,000 hr
Color Rendering Index
80 CRI
Color Temperature
4000 K
Dimmable?
Yes
Fixture Wattage
104 W
Lamp Life
100,000 hr
Lamp Type
LED
Lens Color
Clear
Lens Material
Acrylic
Lumens
15000 lm
Material
Aluminum
Mounting Type
Pendant, Surface, Suspended
Number of Lamps
2
Power Source
Hardwired
Size
14.4x11.5x2.3 IN
Standard
CSA
Style
Traditional
TC Connection
Hardwired
Type
Rectangular
Voltage
120 V
Wattage
105 W

Manufacturer Information

Brand
Acuity Brands
Sub Brand
Compact Pro™

General Product Info

12-Digit UPC
194994429562
Color
White
Construction
New Construction,Remodel
Environment
Indoor
Environmental Conditions
Indoor
Finish
Semi-Gloss
Fixture Type
High Bay
GTIN
00194994429562
Product Type
High Bay
Product UPC
19499442956
Shape
Rectangular
Weight
5 lb

Dimensions

Height
2.3 in
Length
14.4 in
Warranty Length
5 yr
Width
11-1/2 in

Certifications & Compliance

Country of Origin
Mexico,Mexico
Overview
  • WARRANTY: Buy with confidence, 5 year limited warranty
  • VOLTAGE: Multi-volt driver, 120-277V standard
  • INSTALLATION: Fixture is suitable for mounting by chain, cable, surface-mount bracket, pendant monopoint, or hook monopoint
  • DIMMING: Thermally protected driver standard with 0-10V dimming
  • TECHNOLOGY:Glare reduction optics featuring WhiteOptics® Technology allowing for maximum light output while reducing glare
  • ENERGY SAVINGS:LEDs provided 80 color rendering index (CRI), nominal 12,000 lumens at 4000K with a cool white color temperature
  • HOURS OF LIFE: 70% lumen maintenance at > 100,000 hours
  • BATTERY: LED emergency driver sold separately
  • DIMENSIONS: Length 14.4 in. x Width 11.5 in. x Depth 2.3 in.
  • RATINGS: Suitable for damp location, CSA listed.
