Plug ind grade straight nylon 3P4W 250V 30A blk

Manufacturer: Leviton Manufacturing | Catalog # 9432-P | Electrozad South Part # 40455
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet MDM SAFETY DATA SHEET Installation / Instruction Manual MSDS | SDS Safety Sheet D BRAND LOGO IMAGE URL I INSTALL ASSEMBLY INSTRUCTIONS URL
Industrial grade straight blade plug made of super tough nylon. Solid brass blades/contacts and steel, zinc plated assembly screws. Leviton s heavy duty industrial power plugs offer superior performance, long-lasting reliability and features that are backed by a 10-year warranty.

Technical Information

Amperage
30 A
Applications
Industrial
Blade Type
Solid Brass
Body Material
Super Tough Nylon
Conductor Size
10-4 AWG
Cord Size
0.625 - 1.375 in
Device Type
Power Device
Dielectric
2000 V
Grounding
Grounding
Horsepower
2 hp
Material
Super Tough Nylon
Mounting Type
Cable
NEMA
WD-6
Number of Poles
3
Number of Wires
4
Operating Temperature
-40 degrees C
Screw Type
Steel,Zinc-Plated
Size
4.37 H x 2.76 W x 1.89 D IN
Standard
ANSI C-73
Temperature Rating
-40 degrees C to 60 degrees C
Temperature Rise
150 %
Torque
16 lb-in
Type
4-Inlet, 1-Outlet, Rectangular, Power/Communication
Voltage
125/250 V
Wire Count
4
Wire Size
10 - 4 AWG; 0.625 - 1.375 in

Manufacturer Information

Brand
Leviton
Sub Brand
Straight Blade Plugs and Conn

General Product Info

12-Digit UPC
078477809952
Color
Black,Orange,White
Environmental Conditions
Operating Temperature Range (-40 to 60) °C
GTIN
00078477809952
Product UPC
07847780995

Dimensions

Warranty Length
2 yr

Certifications & Compliance

Country of Origin
Mexico
