Pan-Lug™ LCD1/0-12-X Copper Compression Connectors - Lugs

Manufacturer: Panduit | Catalog # LCD1/0-12-X | Electrozad South Part # 407578
$1,869.30 /c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Product Brochure Installation / Instruction Manual D BRAND LOGO IMAGE URL H TECHNICAL DRAWING URL I INSTALL ASSEMBLY INSTRUCTIONS URL
Two-hole, standard barrel lug with window, 1/0 AWG wire, 1/2 stud hole, 1.75 hole spacing.

Technical Information

Angle
Straight
Barrel Length
0.94 in
Barrel Type
Standard with Inspection Window
Cable Size
AWG
Color Coding
Pink
Material
Copper
Number of Holes
2
Size
1/0 AWG Code
Stud Size
0.5 in
Tongue Thickness
0.12 in
Tongue Type
Standard
Tongue Width
0.76 in
Type
Preterminated Copper Trunk, Category 6

Packaging

Package Qty
10

Manufacturer Information

Brand
Panduit
Sub Brand
Pan-Lug™

General Product Info

12-Digit UPC
074983900909
Color
Fresh Pink Lemonade
GTIN
00074983900909
Product UPC
07498390090
UNSPSC
39121405

Dimensions

Overall Length
4.25 in

Certifications & Compliance

BAA | Buy American Compliant
Y
Country of Origin
Mexico
