Plug nylon 2P3W 125V 15A 5-15P black-white

Manufacturer: Bryant Wiring Device | Catalog # BRY5266NP | Electrozad South Part # 41005
$37.22 /ea
pc
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Catalog Page D BRAND LOGO IMAGE URL P WARRANTY URL
Plug made of nylon with 2 pole, 3 wire, 15 A, 125 V, 0.245-0.655 inch, straight blade, industrial device grade.

Technical Information

Amperage
15 A
Applications
Extra Heavy Duty Industrial Application
Conductor Size
14-12 AWG
Cord Type
Portable
Current
15 A
Grounding
Yes
Material
Composite
Mounting Type
Surface
NEMA
5-15P
Number of Phases
1
Number of Poles
2
Number of Wires
3
Size
Standard Sized
Style
Extra Heavy Duty
TC Connection
Screw Terminals
Type
Tech-Spec Triple Gripper, Standard Sized, Industrial Grade
Voltage
125 V
Wattage
1875 W
Wire Size
14-12 AWG

Manufacturer Information

Brand
Bryant
Sub Brand
Bryant

General Product Info

12-Digit UPC
781786005877
Color
Black,White
Environmental Conditions
Indoor Dry Unless Protected by Additional Means
GTIN
00781786005877
Product UPC
78178600587
Weight
0.2 lb

Dimensions

Height
1.38 in
Length
2.18 in
Width
1.52 in

Certifications & Compliance

Country of Origin
China
