LEVITON E5325-W DECORA EDGE RECPT 15A125V WH

Manufacturer: Leviton Manufacturing | Catalog # E5325-W | Electrozad South Part # 415566
*Call For Price*
Log in or register to view your price, purchase history, and more!
26 available

For Delivery

Not in local stock *
Check another branch
Specification Sheet
15 Amp, 125 Volt, NEMA: 5-15R, 2 Pole, 3-Wire, Straight Blade, Decora Duplex Tamper-Resistant Outlet, Self-grounding, UL/CSA, NEC compliant - White

Technical Information

Amperage
15 A
Connection Type
Side Lever
Device Type
Decora Duplex Receptacle
Grounding
Self-Grounding
Number of Poles
2
Number of Wires
3
Termination Type
Color-Coded Levers
Type
Duplex

Manufacturer Information

Brand
Leviton
Sub Brand
Decora®

General Product Info

12-Digit UPC
078477332559
Color
White
GTIN
00078477332559
Product UPC
07847733255

Dimensions

Warranty Length
2 yr

Certifications & Compliance

Country of Origin
China
