SIED HF364 DISCONNECT 200A 3P 3W FUSED HD FUSED HD TYPE 1

Manufacturer: Siemens Distribution | Catalog # HF364 | Electrozad South Part # 425893
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Catalog Page
Siemens Low Voltage Circuit Protection Heavy Duty Safety Switch. 3-Pole 3-Fuse Fused in a type 1 enclosure (indoor). Rated 600VAC (200A). Siemens Low Voltage Circuit Protection Heavy Duty Safety Switch. 3-Pole 3-Fuse Fused in a type 1 enclosure (indoor). Rated 600VAC (200A).

Technical Information

Action
SINGLE THROW
Actuator
SINGLETHROW
Amperage
200 A
Applications
DISCONNECTINGMEANFORSERVICEENTRANCE/LOADS
Connection Type
MECHANICAL LUGS
Enclosure
NEMA1
Material
Punch up to 10 ga mild steel or 12 ga stainless steel.
Number of Poles
3
Operating Cycles
8000
Operating Temperature
-29 degrees C
TC Connection
MECHANICALLUGS
Type
Heavy Duty, Enclosed, Fused, Single Throw, Toggle
Wattage
3 Watt

Manufacturer Information

Brand
Siemens
Sub Brand
VBII

General Product Info

12-Digit UPC
783643151031
GTIN
00783643151031
Product UPC
78364315103
Weight
40.800 lb

Dimensions

Height
10.300 in
Length
34.100 in
Width
20.100 in

Certifications & Compliance

Country of Origin
Mexico
