LIMITRON FAST ACTING FUSE

Manufacturer: Bussman Cooper Fuses | Catalog # CGL-50 | Electrozad South Part # 42673
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 5 to 7 days
Specification Sheet
Eaton Bussmann series Tron CGL HRC form II Class C fuse, 50A, 200 kAIC Vac, 40 kAIC Vdc, Non Indicating, Current-limiting, HRC Form II, Blade end X blade end, Class C

Technical Information

Amperage
50 A
Applications
Circuits Subject To Surge Currents Such as those caused by Motors, Transformers and Other Inductive Loads
Connection Type
Blade
End Type
Blade
Interrupt Rating
200 kA
Size
0.81 In Diameter X 3.50 In Length
TC Connection
Blade End X Blade End
Type
Current Limiting,HRC Form II

Manufacturer Information

Brand
Bussmann
Sub Brand
Bussmann Series

General Product Info

12-Digit UPC
051712100373
Class
C
GTIN
00051712100373
Product UPC
51712100373
Weight
.11 lb

Dimensions

Diameter
.81 in
Height
3.44 in
Length
1.4 in
Width
.81 in
