HUB GFHW13105 INTERRUPTER 30A 120V CIRCUIT GUARD HARD WIRED GFCI 4MA- 6MA TRIP LEVEL AUTO RESET YELLOW | Electrozad South
Product image for HUB GFHW13105 INTERRUPTER 30A 120V CIRCUIT GUARD HARD WIRED GFCI 4MA- 6MA TRIP LEVEL AUTO RESET YELLOW
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Email

HUB GFHW13105 INTERRUPTER 30A 120V CIRCUIT GUARD HARD WIRED GFCI 4MA- 6MA TRIP LEVEL AUTO RESET YELLOW

Manufacturer: Hubbell Wiring Devices | Catalog # GFHW13105 | Electrozad South Part # 4931
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Catalog Page Installation / Instruction Manual
Circuit Guard® Hard Wired 30 Ampere GFCI. UL Type 4X housing. Industrial grade design. Class A GFCI. Operating Temperature: -35..C to +66..C.

Technical Information

Amperage
30 A
Applications
Wire into Circuit
Conductor Material
Copper
Conductor Size
(3) 10 AWG Copper
Conductor Type
Copper
Cord Length
24 in
Current
30 A
Frequency
60 Hz
Insulation Material
Thermoplastic
Number of Conductors
3
Operating Temperature
-30 To 150 degrees F
Reset Type
Automatic
Standard
UL
Style
Automatic Set
Temperature Rating
-34 to 65 degrees C
Type
Industrial Grade, Multi Strand, Fabricated
Voltage
120 V

Manufacturer Information

Brand
Hubbell Wiring Device Kellems
Sub Brand
Hard Wired 30A GFCI

General Product Info

12-Digit UPC
783585005232
Color
Yellow
Construction
Fabricated
GTIN
00783585005232
Housing Material
Thermoplastic
Product Series
Extra Heavy Duty
Product UPC
78358500523
Weight
1.55 lb

Dimensions

Height
6.800 in
Length
3.000 in
Width
5.800 in

Certifications & Compliance

Country of Origin
USA
