Product image for Dry-Shrink™ HSTT150-48-5C Heatshrink, Clear, PO, 4' L, 1.5" to 0.75" ID, PK5
Image thumbnail 0
Image thumbnail 1
Email

Dry-Shrink™ HSTT150-48-5C Heatshrink, Clear, PO, 4' L, 1.5" to 0.75" ID, PK5

Manufacturer: Panduit | Catalog # HSTT150-48-5C | Electrozad South Part # 5728
$30.48 /ea
ea
Log in or register to view your price, purchase history, and more!
2 available

For Delivery

Not in local stock *
Check another branch
Specification Sheet MDM SAFETY DATA SHEET Installation / Instruction Manual MSDS | SDS Safety Sheet D BRAND LOGO IMAGE URL H TECHNICAL DRAWING URL I INSTALL ASSEMBLY INSTRUCTIONS URL
The HSTT150-48-5C Thin Wall Heat Shrink Tubing shrinks around wires, connectors, joints, and terminals when heated to protect against abrasion. Applications include insulating and protecting wires/cables in indoor, dry locations. Shrink ratio: 2:1. Temperature range: -67..F to 275..F (-55..C to 135..C). Cross-linked polyolefin. 1.50... Diameter x 4... Long (38.1 mm x 1.2 m). Color Clear. 5 per package.

Technical Information

Applications
For use with 0.50 inch FM8 conduit bodies. Seals and protects.
Material
Polyolefin
Max Operating Temperature
135 degrees C
Minimum Operating Temperature
-55 degrees C
Shrink Ratio
2:1
Standard
ANSI C-73
Type
Wire-In Heat Detector With Battery Back Up

Packaging

Package Qty
5

Manufacturer Information

Brand
Panduit
Sub Brand
Dry-Shrink

General Product Info

12-Digit UPC
074983906673
Color
Clear
GTIN
00074983906673
Product UPC
07498390667

Dimensions

Inside Diameter
19.1 mm
Outside Diameter
38.1 mm
Overall Length
4 ft
Thickness
1 mm

Certifications & Compliance

BAA | Buy American Compliant
Y
Country of Origin
South Korea
