SIED EQL260S BREAKER CIRCUIT 60A MAX ENCLOSURE

Manufacturer: Siemens Distribution | Catalog # EQL260S | Electrozad South Part # 61124
$100.72 /ea
ea
Log in or register to view your price, purchase history, and more!
8 available

For Delivery

Not in local stock *
Check another branch
Specification Sheet Product Brochure Product Catalog Page Installation / Instruction Manual
Loadcenters are classified into 4 types EQL (1 phase main lug distribution no main), SEQ (1 phase with main breaker), EQ4 (3 phase with main breaker) and EQD(generator suuply) consists of the enclosure, the interior and the trim. Available in version 120/240vac 60/200A-40/80 circuits or 120/208vac 100/225A-12/42 circuits all type eemac 1 interior or 3R outdoor. Made of cold rolled gauge steel finished with gray paint, they are certified listed CSA.

Technical Information

Applications
For Residential
Bus Rating
60 A
Cable Size
3
Conductor Size
3 AWG
Enclosure
Type 1 Indoor
Enclosure Type
Type 1 Indoor
Interrupt Rating
10 kA
Mounting Type
Surface
Number of Circuits
2
Number of Spaces
2S/4S
Size
7x6x2.9 in HxWxD in
Type
EQL, Lockable

Manufacturer Information

Brand
Siemens
Sub Brand
Loadcentres

General Product Info

12-Digit UPC
662862003522
Construction
Steel Housing
Finish
Gray
GTIN
00662862003522
Product UPC
66286200352
