LEVITON 5604-2T SWITCH DECORA LT ALMOND 15A 120V 277V 4WAY QUICKWIRE PUSHIN & SIDE WIRED LIGHT ALMOND

Manufacturer: Leviton Manufacturing | Catalog # 5604-2T | Electrozad South Part # 62895
$25.02 /ea
ea
Log in or register to view your price, purchase history, and more!
2 available

For Delivery

Not in local stock *
Check another branch
Specification Sheet MDM SAFETY DATA SHEET Installation / Instruction Manual MSDS | SDS Safety Sheet
15 Amp, 120/277 Volt, Decora Rocker 4-Way AC Quiet Switch, Residential Grade, Grounding, Quickwire Push-In & Side Wired - Light almond.

Technical Information

Actuator
Rocker
Amperage
12 A
Applications
Residential
Body Material
Thermoplastic
Connection Type
Quickwired Push-In,Side Wired
Contact Rating
120/277 V
Grounding
Grounding
Horsepower
1/2 hp
Material
Thermoplastic
Max Current
12 A
Mounting Type
Wallplate
Number of Poles
4
Operating Temperature
-40 To 120 degrees C
Size
4.20 H x 1.30 W x 0.99 D IN
Standard
CSA,UL
TC Connection
Quickwired Push-In;Side Wired
Temperature Rating
-40 to 120 degrees C
Terminal Type
Screw
Termination Type
Back Wire,Side Wire
Torque
14 lb-in
Type
Quiet,Rocker Switch
Voltage
120/277 V

Manufacturer Information

Brand
Leviton
Sub Brand
Decora®

General Product Info

12-Digit UPC
078477275009
Color
Light Almond
Environmental Conditions
Flammability (Rated V-2 per UL94)
GTIN
00078477275009
Product UPC
07847727500

Dimensions

Warranty Length
2 yr

Certifications & Compliance

Country of Origin
Mexico
