CAT IV FUSED TEST LEADS KIT

Manufacturer: Ideal Industries | Catalog # TLF-014 | Electrozad South Part # 6830
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Product Brochure D BRAND LOGO IMAGE URL
Fused test leads help provide essential safety protection against potentially lethal voltages and short circuit current.

Technical Information

Material
Double Skin Silicone
Temperature Rating
-10 to 150 degrees C
Wire Size
1.1 m

Manufacturer Information

Brand
Ideal

General Product Info

12-Digit UPC
624141017705
Color
White/Red/Black
GTIN
00624141017705
Product UPC
62414101770
Overview
  • Includes: Red/black assembly with fused probes and right-angle plugs (NRTL approved; SEW 52F-L2-4-0.5A4; Conforms to ANSI/UL STD. 61010-031; Certified to CAN/CSA STD. C22.2 No. 61010-031); 2x 1000V ceramic fuses; Screw-on crocodile clips and probe tips
  • EZ-Off caps over probe tips
  • Unique finger-guard protects against accidental high voltage contact
  • All-weather, double-skin silicone insulation with bi-coloured Wear-Guard Damage Control Indicator - a white layer below the red / black layer provides visual indication if cable becomes damaged
  • Specifications: 1.1 m length cable, UL / CSA IEC 61010 CAT IV -1000V Approved, Silicone insulation rated to 10kV DC, Fuse rating: 500mA/1000V/50kA, Temperature rating: -10°C to +150°C
  • Moulded, tug-resistant right-angle plugs (4mm) with strain reliefs fit standard meters
