HUB HBL2621 CONN TL 30A 2P3W 250V MALE PLUG INSULGRIP IP20 2HP NEMA L6-30P BLK&WHT NYLON RETURNABLE

Manufacturer: Hubbell Wiring Devices | Catalog # HBL2621 | Electrozad South Part # 70470
$41.62 /ea
pc
Log in or register to view your price, purchase history, and more!
23 available

For Delivery

Not in local stock *
Check another branch
Specification Sheet Product Catalog Page Installation / Instruction Manual
TWIST-LOCK® Plug insulgrip made of nylon with 2 pole, 3 wire, 250 V, 2 HP.

Technical Information

Amperage
30 A
Applications
Extra Heavy Duty Industrial Application
Conductor Size
12-8 AWG
Cord Type
Portable
Current
30 A
Grounding
Yes
Horsepower
2 hp
Material
Composite
Mounting Type
Surface
NEMA
L6-30P
Number of Phases
1
Number of Poles
2
Number of Wires
3
Operating Temperature
-40 degrees C
Size
2.26 in x 2.26 in x 2.75 in
Standard
CSA C22.2 No.42,Fed.Spec. W-C-596,UL 498
TC Connection
Terminal Screws
Type
Insulgrip, Standard Sized
Voltage
250 V
Wattage
7500 W
Wire Count
3
Wire Size
16-8 AWG

Manufacturer Information

Brand
Hubbell Wiring Device Kellems
Sub Brand
Twist-Lock®, Insulgrip®

General Product Info

12-Digit UPC
783585038834
Color
Black,White
Environmental Conditions
Indoor Dry Unless Protected by Additional Means
GTiN
00783585038834
Product UPC
78358503883
Weight
0.25 lb

Dimensions

Height
2.75 in
Length
2.26 in
Width
2.26 in

Certifications & Compliance

Country of Origin
USA
