SEMI-COND FUSE 80A 150V AC

Manufacturer: Bussman Cooper Fuses | Catalog # FWA-80B | Electrozad South Part # 80674
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 5 to 7 days
Specification Sheet
Eaton Bussmann series FWA high speed fuse, 500V, 80A, 200 kAIC Vac (70-1000A), 20 kAIC at 150 Vdc (70-800A), 100 kAIC at 80 Vdc (70-1000A), None, High speed fuse, Blade end X blade end, Stud

Technical Information

Amperage
80 A
Applications
Installation, Troubleshooting and Preventive Maintenance of Electrical Wiring and Electrical Equipment, Measures 1000 VAC/DC, Resistance and Continuity
Connection Type
Blade
End Type
Blade
Interrupt Rating
70-1000 A
Mounting Type
Stud
Size
1.000 In Diameter X 2.656 In Length
Standard
CSA,E2186,UL
TC Connection
Rod To Blade
Type
P Style, North American
Voltage
500 V

Manufacturer Information

Brand
Eaton
Sub Brand
Bussmann Series

General Product Info

12-Digit UPC
051712577892
Class
Class aR
GTIN
00051712577892
Product UPC
51712577892
Weight
84 g

Dimensions

Height
26 mm
Length
26 mm
