Receptacle 6-15R single decora 15A 250V whi

Manufacturer: Leviton Manufacturing | Catalog # 16651-W | Electrozad South Part # 94940
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet MDM SAFETY DATA SHEET Product Brochure Product Catalog Page MSDS | SDS Safety Sheet D BRAND LOGO IMAGE URL H TECHNICAL DRAWING URL
15 Amp, 250 Volt, NEMA 6-15R, 2P, 3W, Decora Plus Single Receptacle, Straight Blade, Commercial Grade, Self-Grounding, , , Back & Side Wired, Steel Strap, - White

Technical Information

Amperage
15 A
Applications
Commercial use
Body Material
Thermoplastic Nylon
Conductor Size
14-10 AWG
Connection Type
Back and Side Wire
Device Type
Single Receptacle Outlet
Dielectric
2000 V
Dielectric Strength
2000 V
Face Material
Nylon
Flamability Class
Rated V-2 Per UL 94
Grade
Commercial Specification
Grounding
Self-Grounding
Horsepower
1-1/2 hp
Material
Thermoplastic
Mounting Type
Wall Box, Flush, Screw
NEMA
WD-6
Number of Phases
1
Number of Poles
2
Number of Wires
3
Operating Temperature
-40 degrees C
Size
46 H x 1.52 W x 1.14 D IN
Standard
ANSI C-73
TC Connection
Back & Side Wired
Temperature Rating
-40 degrees C to 60 degrees C
Temperature Rise
200 %
Termination Type
Back Wire,Side Wire
Type
Single Outlet,Straight Blade
Voltage
250 V
Wire Count
3,3
Wire Size
14 - 10 AWG

Manufacturer Information

Brand
Leviton
Sub Brand
Decora Plus™

General Product Info

12-Digit UPC
078477474662
Color
White
Environmental Conditions
UL 94 Requirements, V2 Rated Flammability
GTIN
00078477474662
Product UPC
07847747466

Dimensions

Warranty Length
10 yr

Certifications & Compliance

Certifications
UL
Country of Origin
Please Contact Customer Service
