Plug locking ind grade thrmplst 3P4W 600V ylw

Manufacturer: Leviton Manufacturing | Catalog # 28W77 | Electrozad South Part # 95771
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet MDM SAFETY DATA SHEET Product Brochure MSDS | SDS Safety Sheet D BRAND LOGO IMAGE URL
Industrial grade locking plug made of Santoprene TPV. Electroless nickel-coated brass blades/contacts and stainless steel, non-magnetic assembly screws. Leviton's Wetguard line of industrial watertight wiring devices are the most versatile, well-engineered watertight devices.

Technical Information

Actuator
Non-Magnetic,Stainless Steel
Amperage
30 A
Applications
For Industrial Use
Body Material
Santoprene TPV
Conductor Size
12-8 AWG
Connection Type
Screw Terminal
Contact Material
Nickel Plated Brass
Cord Type
SO, ST, STO, SOO
Device Type
Locking Plug
Dielectric
2000 V
Dielectric Strength
2000 V
Flamability Class
Rated V-2 Per UL 94
Grounding
Yes
IP Rating
IP66,IP67,IP69K
Material
Santoprene TPV
Mounting Type
Cable
NEMA
WD-1, WD-6
Number of Phases
3
Number of Poles
3
Number of Wires
4
Operating Temperature
-40 degrees C
Rated Insulation Voltage
2000 V
Rating
UL 498
Screw Type
Electroless,Nickel-Coated Brass,Stainless Steel, Non-Magnetic
Size
2.28 Diameter X 3.61 L IN
Standard
ANSI C-73
TC Connection
Screw Terminal
Temperature Rise
200 %
Terminal Size
#12-8 AWG
Type
Watertight
Voltage
600 V
Wire Count
4
Wire Size
12 - 8 AWG

Manufacturer Information

Brand
Leviton
Sub Brand
Wetguard®

General Product Info

12-Digit UPC
078477969045
Color
Black on Yellow
Environment
Wet
Environmental Conditions
-40 to 60 °C
GTIN
00078477969045
Product UPC
07847796904

Dimensions

Warranty Length
Lifetime Limited

Certifications & Compliance

Country of Origin
Mexico
